AISI 416 - EN 1.4005

Name: AISI 416 - EN 1.4005
Brand: Ninesteel
Price: 100.0 USD
Availability: InStock

Product variants

AISI 416 - EN 1.4005 features a machinability rate of 85% that of a free-machining carbon steel — the highest of any stainless steel — thanks to sulfur added to the composition. Unfortunately, this sulfur decreases its corrosion resistance, weldability, and formability to levels below those of Grade 410.

Equivalent grades

• AISI/ASTM 410
• DIN 1.4006
• UNS S41000
• X12Cr13

Chemical Composition Reference

0.06~0.15C-1Si-1.5Mn-0.04P-0.15~0.35S-12~14Cr-0.6Mo

Physical Property Reference

• Density: 7.75 g/cm³

• Thermal Expansion: 9.9 x10^-6/K

• Modulus of Elasticity: 200 GPa

• Thermal Conductivity: 24.9 W/m.K

• Electrical Resistivity: 0.57 x10^-6 Ω .m

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

AISI 416 - EN 1.4005

Essential details

Corrosion resistance of AISI 416 is lower than the common austenitic grades. Useful resistance to dry atmospheres, fresh water and mild alkalies and acids, but less resistant than the equivalent non-free-machining grades. Less corrosion resistant than the austenitic grades and also less than 17% chromium ferritic alloys such as Grade 430. High sulphur content free machining grades such as 416 are totally unsuitable for marine or other chloride exposure.

Typical Applications:

- Valves, pump shafts and motor shafts

- Parts of washing machines

- Gears, bolts, nuts and studs

- Automatic screw-machined components
