DIN 1.4534 - PH13-8Mo

Name: DIN 1.4534 - PH13-8Mo
Brand: Ninesteel
Price: 100.0 USD
Availability: InStock

Product variants

DIN 1.4534 - PH13-8Mo is a martensitic stainless steel known for its high strength & hardness, plus exceptional resistance to corrosion & stress-corrosion cracking. Approved for use in demanding applications, it is the choice of industries worldwide.

Equivalent grades

• DIN 1.4534
• PH13-8Mo
• UNS S13800
• XM-13

Chemical Composition Reference

12.25~13.25Cr-7.5~8.5Ni-2~2.5Mo-0.9~1.35Al-0.2Mn-0.1N-0.1S-0.05C-0.01P

Physical Property Reference

• Density: 7.76 g/cm³

• Tensile Strength: 1480 MPa

• Yield Strength: 1415 MPa

• Melting Point: 1404°C

• Elogation: 13%

• Modulus of Elasticity: 221 GPa

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

DIN 1.4534 - PH13-8Mo

Essential details

DIN 1.4534 - PH13-8Mo is a stainless steel with 13% chromium and 8% nickel content, providing excellent corrosion resistance and improved mechanical properties in demanding environments compared to other iron-based materials.

Typical Applications:

- Fasteners

- Valves

- Fittings

- Petrochemical Components

- Aircraft Structural parts
