Nickel 201

Name: Nickel 201
Brand: Ninesteel
Price: 100.0 USD
Availability: InStock

Product variants

Nickel 201 is approved for use as a pressure vessel service, which contain gases or liquids at pressures greater than ambient air. According to ASME Boiler and Pressure Vessel Code Section Vl-Division l, it can be used up to 1250°F (677°C).

Equivalent grades

• Nickel 201
• UNS N02201
• W.Nr. 2.4060
• W.Nr. 2.4066

Chemical Composition Reference

99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.01C

Physical Property Reference

• Density: 8.89 g/cm³

• Tensile Strength: 403 MPa

• Yield Strength: 103 MPa

• Melting Point: 1435-1446°C

• Elongation at break: 50%

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

Nickel 201

Essential details

Nickel 201 is commonly used in pressure vessel service. which are containers that carry gases or liquids at a pressurethat is much higher than the ambient pressure. The ASME Boler and Pressure Vessel Code Section Vl-Division l hasapproved it for this use up to 1250°F (about 677°C).

Applications:

- Caustic evaporators

- Combustion boats

- Electronic components

- Plater bars
