Nimonic 75

Name: Nimonic 75
Brand: Ninesteel
Price: 9999.0 USD
Availability: InStock

Product variants

NIMONIC alloy 75 (UNS N06075/W.Nr. 2.4951 & 2.4630) is composed of 80% nickel-chromium, alongside controlled amounts of titanium and carbon. Structures built with this alloy are both easily fabricated and welded. It has excellent creep-rupture strength and is designed to operate in temperatures up to 870°C. NIMONIC alloy 75 also displays good corrosion and oxidation resistance, making it a superior alloy for high temperature applications.

Equivalent grades

• Nimonic 75
• UNS N06075
• W.Nr. 2.4951
• W.Nr. 2.4630
• Alloy 75

Chemical Composition Reference

0.12C-19.5Cr-75Ni-0.4Ti-0.4Fe

Physical Property Reference

• Density: 8.37 g/cm³

• Tensile Strength: 750 MPa

• Yield Strength: 275 MPa

• Modulus of Elasticity: 206 GPa

• Melting Range: 1340-1380°C

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

Nimonic 75

Essential details

NIMONIC® alloy 75 (UNS N06075/W.Nr. 2.4951 &2.4630) is an 80/20 nickel-chromium alloy with controlled additions of titanium and carbon.

First introduced in the 1940s for turbine blades in the prototype Whittle jet engines, it is now mostly used for sheet applications calling for oxidation and scaling resistance coupled with medium strength at high operating temperatures. It is still used in gas turbine engineering and also for industrial thermal processing, furnace components and heat-treatment equipment. It is readily fabricated and welded.

Applications:

- Aerospace fasteners

- Gas turbine engineering

- Industrial furnace structural parts

- Heat treatment equipments

- Nuclear engineering
