UNS N07041 - Haynes R-41

Name: UNS N07041 - Haynes R-41
Brand: Ninesteel
Availability: InStock

Product variants

UNS N07041 is a nickel-chromium alloy that offers superior strength and hardness through precipitation-hardening. Its combination of nickel, chromium, cobalt, molybdenum, aluminum, and titanium makes it an ideal choice for applications requiring the highest levels of strength and durability.

Equivalent grades

• UNS N07041
• Haynes R-41
• DIN 2.4973
• Carpenter 41
• Rene 41
• AISI 683

Chemical Composition Reference

18~20Cr-10~12Co-9~10.5Mo-5Fe-3~3.3Ti-1.4~1.8Al-0.5Si-0.1Mn-(Bal)Ni

Physical Property Reference

• Density: 8.25 g/cm³

• Melting Point: 1333°C

• Tensile Strength: 1420 MPa

• Yield Strength: 1065 MPa

• Thermal conductivity: 11.5 W/mK

Stock & Dimensions

Our warehouse has a large number of stock to provide you with a variety of products in different sizes, and can also customize the size according to your needs.
• Bar: 0.5~600mm Diameter
• Coil: 0.5~150mm Thick
• Plate: 0.5~200mm Thick
• Pipe: 6~630mm External Diameter; 0.5~40mm Wall Tick
• Available in specific sizes

Product Forms

We provide you with a variety of product forms, including but not limited to:
• Bar/Rod
• Pipe/Tube
• Coil/Strip
• Plate/Sheet/Circle
• Wire
• Fitting (Flange, Elbow, Tee...)
• Customize

View full details

UNS N07041 - Haynes R-41

Essential details

UNS N07041 - Haynes R-41 is a nickel-based alloy with strength and ductility perfect for gas turbine engine parts. Solution annealing and heat treatments further improve the alloy's strength, up to 1800°F (649 to 982°C). It's as strong as 18-8 stainless steel but more resistant to forming, making it ideal for drop hammers, expanding mandrels and stretch forming.

Applications:

- Aircraft

- Gas turbine

- Land/Marine
